Door Access Switches

Door Access Switches

Heavy Duty Switches

Hand-E-Wave™

HEWMO-20

Hand-E-Wave is a rugged, stainless steel, hands-free switch with advanced 24GHz Doppler radar technology. Hand-E-Wave is designed to operate in all environments including sterile facilities (hospitals, clean rooms, and food processing plants). Typically installed to trigger an automatic door opener, Hand-E-Wave‘s low profile, recessed design, and no touch switch technology help reduce the spread of bacteria, infectious diseases and HAI’s (healthcare-associated infections).

  • Input Voltage: 12 - 24VAC/DC
  • One 2A Relay (30VDC Resistive)
  • Adjustable Output Time (1 to 30 sec)
  • Fail Safe or Fail Secure Operation
  • Audio/Visual Feedback
  • Adjustable Detection Zone (2" to 24")
  • Stainless Steel Construction
  • Rugged Low Profile Design
  • Easy to Clean & Sanitize
  • Narrow, Single, or Double Gang Versions
  • Optional Manual Override
  • Customizable Graphics



For more information, visit Hand-E-Wave

Hand-E-Wave™

HEWMO-20

Hand-E-Wave is a rugged, stainless steel, hands-free switch with advanced 24GHz Doppler radar technology. Hand-E-Wave is designed to operate in all environments including sterile facilities (hospitals, clean rooms, and food processing plants). Typically installed to trigger an automatic door opener, Hand-E-Wave‘s low profile, recessed design, and no touch switch technology help reduce the spread of bacteria, infectious diseases and HAI’s (healthcare-associated infections).

  • Input Voltage: 12 - 24VAC/DC
  • One 2A Relay (30VDC Resistive)
  • Adjustable Output Time (1 to 30 sec)
  • Fail Safe or Fail Secure Operation
  • Audio/Visual Feedback
  • Adjustable Detection Zone (2" to 24")
  • Stainless Steel Construction
  • Rugged Low Profile Design
  • Easy to Clean & Sanitize
  • Narrow, Single, or Double Gang Versions
  • Optional Manual Override
  • Customizable Graphics



For more information, visit Hand-E-Wave

Hand-E-Tap™

PHSS1-hand-e-tap

Hand-E-Tap®, the first programmable, ADA compliant access button built with Essex Piezoelectric Switch Technology. This extremely rugged, vandal resistant switch is designed to operate in a variety of high use, harsh, interior or exterior, industrial and commercial environments. Easy to use for all users including the sight, hearing or physically impaired. Essex Billion Cycle Switch Technology™ allows the switch to be operated with a light tap on any area of the switch even with a gloved hand, elbow or cane.

The Essex Hand-E-Tap® Series

  • 1 SPDT Relay (Rated 8A at 30VDC, 125VAC)
  • Field Programmable Output: Toggle (On/Off) or Adjustable 1 to 60 Seconds
  • Stainless Steel Construction (316L)
  • Custom Graphics Available
  • ADA Compliant Switch



For more information, visit Hand-E-Tap®

Hand-E-Tap™

PHSS1-hand-e-tap

Hand-E-Tap®, the first programmable, ADA compliant access button built with Essex Piezoelectric Switch Technology. This extremely rugged, vandal resistant switch is designed to operate in a variety of high use, harsh, interior or exterior, industrial and commercial environments. Easy to use for all users including the sight, hearing or physically impaired. Essex Billion Cycle Switch Technology™ allows the switch to be operated with a light tap on any area of the switch even with a gloved hand, elbow or cane.

The Essex Hand-E-Tap® Series

  • 1 SPDT Relay (Rated 8A at 30VDC, 125VAC)
  • Field Programmable Output: Toggle (On/Off) or Adjustable 1 to 60 Seconds
  • Stainless Steel Construction (316L)
  • Custom Graphics Available
  • ADA Compliant Switch



For more information, visit Hand-E-Tap®

PEB Series

PEB-2S

PEB Series Piezoelectric Switches are industrial-grade illuminated, stainless steel, timed electronic switches designed to operate in various high use, harsh, and vandal prone environments. Suitable for both indoor and outdoor commercial applications, the PEB Series features a unique selectable, bi-colored illumination status. Brilliant red, vibrant green or no illumination can be selected to show Relay ON or Relay OFF status. Illumination can also be controlled externally.

  • Input Voltage: 12 - 24VDC
  • Two Outputs: 1 N/O, 1 N/C
  • One 2A Relay (30VDC Resistive)
  • Fail Safe or Fail Secure Operation
  • Field Selectable Illumination
  • Adjustable Output Time (1 to 40 sec.)
  • Stainless Steel Construction
  • Circuit Assembly Encapsulation
  • Vandal Resistant Design
  • Narrow or Single Gang Versions
  • Low profile, recessed design
  • Customizable Graphics



For more information, visit PEB Series

PEB Series

PEB-2S

PEB Series Piezoelectric Switches are industrial-grade illuminated, stainless steel, timed electronic switches designed to operate in various high use, harsh, and vandal prone environments. Suitable for both indoor and outdoor commercial applications, the PEB Series features a unique selectable, bi-colored illumination status. Brilliant red, vibrant green or no illumination can be selected to show Relay ON or Relay OFF status. Illumination can also be controlled externally.

  • Input Voltage: 12 - 24VDC
  • Two Outputs: 1 N/O, 1 N/C
  • One 2A Relay (30VDC Resistive)
  • Fail Safe or Fail Secure Operation
  • Field Selectable Illumination
  • Adjustable Output Time (1 to 40 sec.)
  • Stainless Steel Construction
  • Circuit Assembly Encapsulation
  • Vandal Resistant Design
  • Narrow or Single Gang Versions
  • Low profile, recessed design
  • Customizable Graphics



For more information, visit PEB Series

Hand-E-Wave™

HEWMO-20

Hand-E-Wave is a rugged, stainless steel, hands-free switch with advanced 24GHz Doppler radar technology. Hand-E-Wave is designed to operate in all environments including sterile facilities (hospitals, clean rooms, and food processing plants). Typically installed to trigger an automatic door opener, Hand-E-Wave‘s low profile, recessed design, and no touch switch technology help reduce the spread of bacteria, infectious diseases and HAI’s (healthcare-associated infections).

  • Input Voltage: 12 - 24VAC/DC
  • One 2A Relay (30VDC Resistive)
  • Adjustable Output Time (1 to 30 sec)
  • Fail Safe or Fail Secure Operation
  • Audio/Visual Feedback
  • Adjustable Detection Zone (2" to 24")
  • Stainless Steel Construction
  • Rugged Low Profile Design
  • Easy to Clean & Sanitize
  • Narrow, Single, or Double Gang Versions
  • Optional Manual Override
  • Customizable Graphics



For more information, visit Hand-E-Wave

Hand-E-Wave™

HEWMO-20

Hand-E-Wave is a rugged, stainless steel, hands-free switch with advanced 24GHz Doppler radar technology. Hand-E-Wave is designed to operate in all environments including sterile facilities (hospitals, clean rooms, and food processing plants). Typically installed to trigger an automatic door opener, Hand-E-Wave‘s low profile, recessed design, and no touch switch technology help reduce the spread of bacteria, infectious diseases and HAI’s (healthcare-associated infections).

  • Input Voltage: 12 - 24VAC/DC
  • One 2A Relay (30VDC Resistive)
  • Adjustable Output Time (1 to 30 sec)
  • Fail Safe or Fail Secure Operation
  • Audio/Visual Feedback
  • Adjustable Detection Zone (2" to 24")
  • Stainless Steel Construction
  • Rugged Low Profile Design
  • Easy to Clean & Sanitize
  • Narrow, Single, or Double Gang Versions
  • Optional Manual Override
  • Customizable Graphics



For more information, visit Hand-E-Wave

PEB Series

PEB-2S

PEB Series Piezoelectric Switches are industrial-grade illuminated, stainless steel, timed electronic switches designed to operate in various high use, harsh, and vandal prone environments. Suitable for both indoor and outdoor commercial applications, the PEB Series features a unique selectable, bi-colored illumination status. Brilliant red, vibrant green or no illumination can be selected to show Relay ON or Relay OFF status. Illumination can also be controlled externally.

  • Input Voltage: 12 - 24VDC
  • Two Outputs: 1 N/O, 1 N/C
  • One 2A Relay (30VDC Resistive)
  • Fail Safe or Fail Secure Operation
  • Field Selectable Illumination
  • Adjustable Output Time (1 to 40 sec.)
  • Stainless Steel Construction
  • Circuit Assembly Encapsulation
  • Vandal Resistant Design
  • Narrow or Single Gang Versions
  • Low profile, recessed design
  • Customizable Graphics



For more information, visit PEB Series

PEB Series

PEB-2S

PEB Series Piezoelectric Switches are industrial-grade illuminated, stainless steel, timed electronic switches designed to operate in various high use, harsh, and vandal prone environments. Suitable for both indoor and outdoor commercial applications, the PEB Series features a unique selectable, bi-colored illumination status. Brilliant red, vibrant green or no illumination can be selected to show Relay ON or Relay OFF status. Illumination can also be controlled externally.

  • Input Voltage: 12 - 24VDC
  • Two Outputs: 1 N/O, 1 N/C
  • One 2A Relay (30VDC Resistive)
  • Fail Safe or Fail Secure Operation
  • Field Selectable Illumination
  • Adjustable Output Time (1 to 40 sec.)
  • Stainless Steel Construction
  • Circuit Assembly Encapsulation
  • Vandal Resistant Design
  • Narrow or Single Gang Versions
  • Low profile, recessed design
  • Customizable Graphics



For more information, visit PEB Series
