SKE-34SE

SKE-34SE

Self Contained Elevator Access Control Keypad

ALL INCLUSIVE ACCESS

The SKE-34 is a heavy duty, self-contained Access Control Keypad with features suitable for landing and single stop elevator applications. With a 2A relay on board, simply add power [5VDC or 12 to 24VDC] and the SKE-34 is ready to provide dependable access control. Rugged Stainless Steel construction and proprietary Piezoelectric Billion Cycle Switch Technology ensures superior performance in any environment. The SKE-34 used for elevator applications is backed by a 2-year limited warranty.

  • Self Contained Access Control
  • 3 Programmable Outputs
  • Up to 500 User Codes
  • Easy to install and operate
  • Laser Marked Keypad Graphics
  • Lower Cost Self Contained Design
  • Keypad Programmable
  • Keyless Throwover

Easily programmable through the Keypad, the SKE-34 features 502 codes (1 Master, 500 User and 1 Temporary) and 3 Programmable Outputs (1 SPDT Relay rated at 2A at 24V max and 2 Open Collector 1/4A max to ground). Two 1/4A grounding outputs are available which can control an auxiliary device.

The SKE-34 Elevator Series is CSA listed for Elevator Access Control (CSA B44.1/ASME 17.5).

For information regarding any of the Elevator Keyless Entry Access Control Systems listed on this site, please contact Essex directly at 1-800-KEYLESS.

ALL INCLUSIVE ACCESS

The SKE-34 is a heavy duty, self-contained Access Control Keypad with features suitable for landing and single stop elevator applications. With a 2A relay on board, simply add power [5VDC or 12 to 24VDC] and the SKE-34 is ready to provide dependable access control. Rugged Stainless Steel construction and proprietary Piezoelectric Billion Cycle Switch Technology ensures superior performance in any environment. The SKE-34 used for elevator applications is backed by a 2-year limited warranty.

  • Self Contained Access Control
  • 3 Programmable Outputs
  • Up to 500 User Codes
  • Easy to install and operate
  • Laser Marked Keypad Graphics
  • Lower Cost Self Contained Design
  • Keypad Programmable
  • Keyless Throwover

Easily programmable through the Keypad, the SKE-34 features 502 codes (1 Master, 500 User and 1 Temporary) and 3 Programmable Outputs (1 SPDT Relay rated at 2A at 24V max and 2 Open Collector 1/4A max to ground). Two 1/4A grounding outputs are available which can control an auxiliary device.

The SKE-34 Elevator Series is CSA listed for Elevator Access Control (CSA B44.1/ASME 17.5).

For information regarding any of the Elevator Keyless Entry Access Control Systems listed on this site, please contact Essex directly at 1-800-KEYLESS.
